Cup Density Meter DH08

DH08 is a cup type of portable density meter, which provides automatic temperature compensation and measures the density digitally, it is used for density measurement for sampling products manually taken from a tanker truck or from a tank in station or a terminal to determine the quality or purity  of the products.

Share:
Cup Density Meter DH08

DH08 is a cup type of portable density meter, which provides automatic temperature compensation and measures the density digitally, it is used for density measurement for sampling products manually taken from a tanker truck or from a tank in station or a terminal to determine the quality or purity  of the products.



      • Require only a small sample of volume;
      • Campac and convinient to be take along to the field site;
      • Easy operation thanks to the well arranged user interface and touch screen display;
      • Real time measuring and displaying the measurement values;
      • Complete data recording and back up; documentation of all measured values of last 2000 measurements;
      • Convinient transfer of data measured to the PC;
      • Seamless measurement process including recording data and downloading data to PC/ ERP system, which securing the measurement authenticity and objectivity;
      • Data is availibe to be exported into a Excel format and to be printed.

Measuring Accuracy of density

±0.3kg/m3

Measuring Accuracy of temperature

±0.1℃

Measure Density Range

1~2000kg/m3

Repeatability Error

< ± 0.1 kg/m3

Allowed Humidity

15%~90%RH

Working Temperature

-40℃ ~ +70℃

Temperature compensation

Automatic

Communication

433MHz wireless communication

Material of the measurement parts

Stainless steel 316; Hastelloy

Protect Class

Sensor: IP68; Other parts: IP65

Explosion-proof Rating

Ex ia IIC T4Ga

Dislay

OLED 8*16 dot-matrix

Data Storage

2024
